Product Details:
|
| Applicable Industries: | Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Advertising C | Showroom Location: | Egypt, Canada, Turkey, United Kingdom, United States, Italy, France, Germany, Viet Nam, Philippines, Brazil, Peru, Saudi Arabia, Indonesia, Pakistan, India, Mexico, Russia, Spain, Thailand, Morocco, Kenya, Argentina, South Korea, Chile, UAE, Colombia, Alge |
|---|---|---|---|
| Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Marketing Type: | New Product 2022 | Warranty Of Core Components: | 1 Year |
| Core Components: | Motor, PLC | Warranty: | 1 Year |
| Productivity: | 500L/Hour | Weight (KG): | 500 Kg |
| After-sales Service Provided: | Video Technical Support | Product Name: | Chlorine Dioxide Generator For Swimming Pool Water Treatment |
| Type: | BT | Material: | PVC |
| Application: | Wastewater Treatment | Function: | Wastewater Disinfection |
| Color: | White/Customized | Key Words: | Chlorine Dioxide Generator For Swimming Pool Water Treatment |
| Usage: | Wastewater Treatment | Port: | Qingdao |
1. Composition:
It consists of feeding system, reaction system, control system, mixing and absorption system, security system.
2. Reaction Principle:
NaCLO3+2HCL→CLO2+1/2CL2+NaCL+H2O
Raw material: Sodium chlorate(GB/T1618-1995, content: more than 99%),
Hhydrochloric acid(GB320-93, concentration : more than 31%).
3. Features:
(1) For production of compound disinfectant (chlorine dioxide as main, chlorine gas as auxiliary), calculated by available chlorine, CLO2 : more than 75%.
(2) Flow-meter dosage system for transferring raw material ensures simple operation, accurate material input, un-blockage and stable performance.
(3) Main reaction pot adopts imported compound material that is temperature-resistant, anti-corrosion with long life time.
(4) Total convertible rate of raw material≥85%,low energy consumption.
(5) Semi-auto run of machine, no need of extra worker if there’s enough material.
(6) Upper-positioned material basket is suitable for low water pressure area.
4. Consumption of raw material:
1g available chlorine consumes 0.65g sodium chlorate and 1.3g hydrochloric acid
5. Technical Parameters:
|
Model |
Available chlorine output(g/h) |
Pressure(Mpa) |
DN1(mm) |
DN(mm) |
Power(Kw) |
|
BT-50 |
50 |
≥0.20 |
25 |
32 |
0.5 |
|
BT-100 |
100 |
≥0.20 |
25 |
32 |
0.5 |
|
BT-200 |
200 |
≥0.20 |
25 |
32 |
0.5 |
|
BT-300 |
300 |
≥0.20 |
25 |
32 |
0.5 |
|
BT-500 |
500 |
≥0.20 |
25 |
32 |
0.5 |
|
BT-800 |
800 |
≥0.20 |
25 |
32 |
0.5 |
|
BT-1000 |
1000 |
≥0.20 |
32 |
40 |
0.5 |
