Cremation Machine WFS Waste Incinerator Gasification And Melting Furnace

Cremation Machine WFS Waste Incinerator Gasification And Melting Furnace
Cremation Machine WFS Waste Incinerator Gasification And Melting Furnace Cremation Machine WFS Waste Incinerator Gasification And Melting Furnace Cremation Machine WFS Waste Incinerator Gasification And Melting Furnace Cremation Machine WFS Waste Incinerator Gasification And Melting Furnace Cremation Machine WFS Waste Incinerator Gasification And Melting Furnace Cremation Machine WFS Waste Incinerator Gasification And Melting Furnace

Large Image :  Cremation Machine WFS Waste Incinerator Gasification And Melting Furnace

Product Details:
Place of Origin: Shandong, China
Brand Name: Better
Certification: ISO9001
Model Number: WFS
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: $3,999.00/sets 1-1 sets
Packaging Details: Seaworthy package
Supply Ability: 15 Set/Sets per Month

Cremation Machine WFS Waste Incinerator Gasification And Melting Furnace

Description
Applicable Industries: Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Advertising C Showroom Location: Egypt, Canada, Turkey, United Kingdom, United States, Italy, France, Germany, Viet Nam, Philippines, Brazil, Peru, Saudi Arabia, Indonesia, Pakistan, India, Mexico, Russia, Spain, Thailand, Morocco, Kenya, Argentina, South Korea, Chile, UAE, Colombia, Alge
Type: Solid Incinerator Warranty: 1 Year
Power: 7.5kw Material: Ss/cs, Carbon Steel
Production Capacity: 750L/H Machinery Test Report: Provided
Video Outgoing-inspection: Provided Marketing Type: New Product 2020
Warranty Of Core Components: 1 Year Core Components: Burner
Weight (KG): 1000 Kg After-sales Service Provided: Field Installation, Commissioning And Training
Name: Gasification And Melting Furnace,Dead Pets Cremation Machine Color: Silver Grey/black/customized
Capacity: 10-5000kg/batch Fuel: Diesel Oil/LPG/natural Gas
Size: WFS 20-500 Application: Dead Animal Body
Weight: 2300-13000kg Port: Qingdao/Rizhao



Cremation Machine WFS Waste Incinerator Gasification And Melting Furnace 0
PRODUCT DESCRIPTION
Cremation Machine WFS Waste Incinerator Gasification And Melting Furnace 1

Description:
WFS Series Waste Incinerator is a kind of machine that was developed on the basis of Japanese technology, absorbs advantages of
similar equipment both at home and abroad. It features unique and advanced merits with compact size, high burning effect,
reasonable burning technology, high degree of non-harm etc.It is an ideal choice for waste treatment of hospitals, hotels and
various areas.

Features:

(1) Gasifiedpyrolysis incineration is used for burning many kinds of waste.

(2) Waste can be burned once everyday by gasified incineration.

(3) Gasified incineration, mixed incineration and burnout treatment ensures low emission standard of dust,dioxin etc.

(4) Totally enclosed operation is suitable for treating infectious waste to avoid secondary pollution.

(5) Compact structure and small land occupation.
Model
WFS-30
WFS-50
WFS-150
WFS-300
WFS-500
Burning Capacity
20-30kg/time (3-6 times/day)
30-50kg/time (3-6times/day)
100-150kg/time (3-6times/day)
200-300kg/time (3-6times/day)
300-400kg/time(3-6times/day)
Incinerator Size m (L*H*B)
1.45*0.9*1.75
1.8*1.15*3
2*1.4*3.5
2.2*1.4*3.8
3*2*4.8
Imputing Mouth Width (mm)
480*600
620*800
760*960
900*1100
1080*1280
Chimney External Diameter
(mm)
280
280
300
400
460
Draught Fan
0.37kw
0.37kw
0.5kw
1.1kw
1.1kw/0.55kw
Combustion Improver Device
0.11kw
Oil consumption: 4-6kg/h
0.11kw
Oil consumption: 4-10kg/h
0.11kw
Oil consumption: 4-10kg/h
0.22kw
Oil consumption: 7-14kg/h
0.22kw
Oil consumption: 7-14kg/h
Re-Burning Device
0.11 kw
Oil consumption 4-6 kg/h
0.11kw
Oil consumption: 4-10kg/h
0.22kw
Oil consumption: 7-14kg/h
0.37kw
Oil consumption: 10-20kg/h
0.37kw
Oil consumption: 15-26kg/h
Voltage
380v/220v
380v/220v
380v/220v
380v/220v
380v/220v
More Model Information, Please Contact Us.
Cremation Machine WFS Waste Incinerator Gasification And Melting Furnace 2
Cremation Machine WFS Waste Incinerator Gasification And Melting Furnace 3
Cremation Machine WFS Waste Incinerator Gasification And Melting Furnace 4
Cremation Machine WFS Waste Incinerator Gasification And Melting Furnace 5
Cremation Machine WFS Waste Incinerator Gasification And Melting Furnace 6
Cremation Machine WFS Waste Incinerator Gasification And Melting Furnace 7
Cremation Machine WFS Waste Incinerator Gasification And Melting Furnace 8
Cremation Machine WFS Waste Incinerator Gasification And Melting Furnace 9
Cremation Machine WFS Waste Incinerator Gasification And Melting Furnace 10
Cremation Machine WFS Waste Incinerator Gasification And Melting Furnace 11
WFS series of life ( medical) waste incinerator is used in a pyrolysis gasification and the most a dvanced around the wind mixed fuel + .two + bum treatment of incineration. The incinerator in a combustion chamber design due to the gasification incineration technology makes the temperature of incinerator furmace goes from 200 to 400 degrees Celsius never produced incombustion process clinker. slag, sintering and other problems.

In the two mixed burning chamber is provided with two times burning burner and tangential air-supply device. At high temperature. the combustible gas in the flue gas can burn fully. can be eficient to gas and air produced by the gasification furnaceis fully mixed combustion. prevent the occurence of carbon material escape styles and delayed firing phenomenon.

The flue gas in the high temperature. combustion chamber with tangential entry and combustion air into the combustion mode etc.. the flue gas in the combustion chamber can be flly burning and the use of rotary flow of flue gas dust removal, incineration fue gas residence time in the fumace more than 2seconds. the combustible gas in the fue gas and fly ash completely burned.a dry exhaust gas purification device on the upper part of the incinerator. the adsorption of hydrogen chloride.

Sulfur oxide generated in the incineration. flue gas odor components are decomposed at high temperature. with calcium hydride flter tiles and acid gas and reaction gas Cleaning system. the adsorption of acid gases. the purpose of tail gas purification. The harmful components in smoke is reduced to the national" hazardous waste incineration pollution control standards ( GB18484 2001 )”and other standard below the specified valve.

Cremation Machine WFS Waste Incinerator Gasification And Melting Furnace 12

Cremation Machine WFS Waste Incinerator Gasification And Melting Furnace 13
APPLICATION
Cremation Machine WFS Waste Incinerator Gasification And Melting Furnace 14
Cremation Machine WFS Waste Incinerator Gasification And Melting Furnace 15
