Product Details:
|
| Condition: | New | Applicable Industries: | Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Advertising C |
|---|---|---|---|
| Showroom Location: | Egypt | Type: | Solid Waste Incinerator |
| Warranty: | 1 Year, 1year | Power: | 7.5kw |
| Material: | Ss/cs, Carbon Steel With Refractory Material | Production Capacity: | 1000L/H |
| Machinery Test Report: | Provided | Video Outgoing-inspection: | Provided |
| Marketing Type: | New Product 2019 | Warranty Of Core Components: | 1 Year |
| Core Components: | Motor | Weight (KG): | 3000 Kg |
| Capacity: | 30-500kgs/time | Fuel: | Diesel/Natural Gas/LPG |
| Application: | Hospital/Residential Quarter/Station | Thickness: | 5mm |
| Installation: | 3D Installation Video Are Provided | Chimney: | 6m |
| Color: | Silver/Grey/Black/Others |
Model | WFS-30 | WFS-50 | WFS-150 | WFS-300 | WFS-500 |
Burning Capacity | 20-30kg/time (3-6 times/day) | 30-50kg/time (3-6times/day) | 100-150kg/time (3-6times/day) | 200-300kg/time (3-6times/day) | 300-400kg/time(3-6times/day) |
Incinerator Size m (L*H*B) | 1.45*0.9*1.75 | 1.8*1.15*3 | 2*1.4*3.5 | 2.2*1.4*3.8 | 3*2*4.8 |
Imputing Mouth Width (mm) | 480*600 | 620*800 | 760*960 | 900*1100 | 1080*1280 |
Chimney External Diameter (mm) | 280 | 280 | 300 | 400 | 460 |
Draught Fan | 0.37kw | 0.37kw | 0.5kw | 1.1kw | 1.1kw/0.55kw |
Combustion Improver Device | 0.11kw Oil consumption: 4-6kg/h | 0.11kw Oil consumption: 4-10kg/h | 0.11kw Oil consumption: 4-10kg/h | 0.22kw Oil consumption: 7-14kg/h | 0.22kw Oil consumption: 7-14kg/h |
Re-Burning Device | 0.11 kw Oil consumption 4-6 kg/h | 0.11kw Oil consumption: 4-10kg/h | 0.22kw Oil consumption: 7-14kg/h | 0.37kw Oil consumption: 10-20kg/h | 0.37kw Oil consumption: 15-26kg/h |
Voltage | 380v/220v | 380v/220v | 380v/220v | 380v/220v | 380v/220v |
