Product Details:
|
Condition: | New | Applicable Industries: | Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Home Use, Retail, Construction Works , Energy & Mining |
---|---|---|---|
Showroom Location: | Egypt, Canada, Turkey, United Kingdom, United States, Italy, France, Germany, Viet Nam, Philippines, Brazil, Peru, Saudi Arabia, Indonesia, Pakistan, India, Mexico, Russia, Spain, Thailand, Morocco, Kenya, Argentina, Chile, UAE, Colombia, Algeria, Sri Lank | Type: | Incinerator |
Warranty: | 1 Year | Production Capacity: | 750L/H |
Machinery Test Report: | Provided | Video Outgoing-inspection: | Provided |
Marketing Type: | New Product 2022 | Warranty Of Core Components: | 1 Year |
Core Components: | Motor | Weight (KG): | 1000 Kg |
After Warranty Service: | Video Technical Support | After-sales Service Provided: | Field Maintenance And Repair Service |
Color: | Silver/ Blue | Capacity: | 10-500kgs/batch |
Material: | High Temperature Resistant Paint For Q235 Carbon Steel | Application: | Solid Waste |
Quick Delivery: | Within 5 Days After Receipt Of Payment | Port: | Qingdao |
Model | WFS-30 | WFS-50 | WFS-150 | WFS-300 | WFS-500 |
Burning Capacity | 20-30kg/time (3-6 times/day) | 30-50kg/time (3-6times/day) | 100-150kg/time (3-6times/day) | 200-300kg/time (3-6times/day) | 300-400kg/time(3-6times/day) |
Incinerator Size m (L*H*B) | 1.45*0.9*1.75 | 1.8*1.15*3 | 2*1.4*3.5 | 2.2*1.4*3.8 | 3*2*4.8 |
Imputing Mouth Width (mm) | 480*600 | 620*800 | 760*960 | 900*1100 | 1080*1280 |
Chimney External Diameter (mm) | 280 | 280 | 300 | 400 | 460 |
Draught Fan | 0.37kw | 0.37kw | 0.5kw | 1.1kw | 1.1kw/0.55kw |
Combustion Improver Device | 0.11kw Oil consumption: 4-6kg/h | 0.11kw Oil consumption: 4-10kg/h | 0.11kw Oil consumption: 4-10kg/h | 0.22kw Oil consumption: 7-14kg/h | 0.22kw Oil consumption: 7-14kg/h |
Re-Burning Device | 0.11 kw Oil consumption 4-6 kg/h | 0.11kw Oil consumption: 4-10kg/h | 0.22kw Oil consumption: 7-14kg/h | 0.37kw Oil consumption: 10-20kg/h | 0.37kw Oil consumption: 15-26kg/h |
Voltage | 380v/220v | 380v/220v | 380v/220v | 380v/220v | 380v/220v |
