Wastewater Pre-treatment Dissolved Air Flotation and Micro-Bubble Adsorption Treatment

Wastewater Pre-treatment Dissolved Air Flotation and Micro-Bubble Adsorption Treatment
Wastewater Pre-treatment Dissolved Air Flotation and Micro-Bubble Adsorption Treatment Wastewater Pre-treatment Dissolved Air Flotation and Micro-Bubble Adsorption Treatment Wastewater Pre-treatment Dissolved Air Flotation and Micro-Bubble Adsorption Treatment Wastewater Pre-treatment Dissolved Air Flotation and Micro-Bubble Adsorption Treatment Wastewater Pre-treatment Dissolved Air Flotation and Micro-Bubble Adsorption Treatment Wastewater Pre-treatment Dissolved Air Flotation and Micro-Bubble Adsorption Treatment

Large Image :  Wastewater Pre-treatment Dissolved Air Flotation and Micro-Bubble Adsorption Treatment

Product Details:
Place of Origin: Shandong, China
Brand Name: BETTER
Certification: CE ISO9001
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: $6,588.00/pieces 2-2 pieces
Packaging Details: Seaworthy packing-- garbage incinerator,poultry incinerator,mini waste incinerator
Supply Ability: 15 Set/Sets per Month
Contact Now

Wastewater Pre-treatment Dissolved Air Flotation and Micro-Bubble Adsorption Treatment

Description
Condition: New Applicable Industries: Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Advertising C
Showroom Location: Egypt, Canada, Italy, France, Germany, Pakistan, India, Mexico, Russia, Spain, Thailand, Morocco, Kenya, Argentina, Colombia, South Africa, Australia Video Outgoing-inspection: Provided
Machinery Test Report: Provided Marketing Type: Hot Product 2023
Warranty Of Core Components: 1 Year Core Components: Pump, Motor, Scraper, Air Compressor, Dissolved Air Tank
Material: Seaworthy Package, Stainless Steel/carbon Steel Weight: 1000kg
Size: According To Model Power: 3-37kw
Warranty: 1 Year Productivity: 3000L/Hour
Weight (KG): 1000 Kg Product Name: Dissolved Air Flotation
Capacity: 5-300m3/h Type: Pure Water Treatment System
After-sales Service Provided: Video Technical Support\Online Support Color: Silver/blue/black/white/green
Feature: Environment Friendly Shape: Rectangle
Usage: Wastewater Pre-treatment Port: Port Of Qingdao

PRODUCT DESCRIPTION
YW series Dissolved Air Flotation is mainly for solid-liquid or liquid-liquid separation. Large sum of micro bubbles produced by dissolving and releasing system adhere to solid or liquid particles with same density as waste water to make the whole float to the surface thus achieve the aim of solid-liquid or liquid-liquid separation.
Wastewater Pre-treatment Dissolved Air Flotation and Micro-Bubble Adsorption Treatment 0
Wastewater Pre-treatment Dissolved Air Flotation and Micro-Bubble Adsorption Treatment 1
Wastewater Pre-treatment Dissolved Air Flotation and Micro-Bubble Adsorption Treatment 2
Wastewater Pre-treatment Dissolved Air Flotation and Micro-Bubble Adsorption Treatment 3
Model
Capacity
(m³/h)
Dissolved Gas water
(m³/h)
Main dynamo power
(KW)
Foam scraper power
(KW)
Air compressor power
(KW)
Dissolved air tank size
(mm)
Overall dimension
(mm)

YW-5
4-5
1.5-2
3
0.55
1.5
φ400×1000
3300×1800×2000
YW-10
8-10
2-3
4
0.55
1.5
φ500×1512
4000×2100×2200
YW-20
15-20
5-7
7.5
0.55
1.5
φ500×1512
4600×2400×2200
YW-30
20-30
6-10
7.5
0.55
1.5
φ500×1512
5200×2600×2400
YW-40
30-40
8-13
7.5
0.75
2.2
φ600×1880
6000×2600×2400
YW-50
40-50
15-20
7.5
0.75
2.2
φ600×1880
7000×2600×2400
YW-60
50-60
18-27
11
0.75
2.2
φ600×1880
7600×2800×2400
YW-70
60-70
22-30
11
0.75
2.2
φ650×2034
8400×2800×2400
YW-80
70-80
24-32
11
0.75
3
φ650×2034
9200×2800×2400
YW-105
90-105
30-35
15
1.5
3
φ700×1980
10000×2800×2600
YW-150
125-150
60-80
22
1.1
4
φ700×1980
13500×2800×2600
YW-200
175-200
80-100
30
1.1
5.5
φ800×2100
15800×2800×2600
YW-250
225-250
100-120
37
1.1
5.5
φ800×2400
15200×3400×2600
YW-300
280-300
120-180
37
1.1
5.5
φ1000×2900
19200×3400×2800
APPLICATION
Wastewater Pre-treatment Dissolved Air Flotation and Micro-Bubble Adsorption Treatment 4

1.Separation of oily(including emulsified) wastewater from petroleum, chemical and mechanical processes.
2.Recovery of sewage organic matter.(such as recovery of pulp fibers and fillers from paper mill wastewater).
3.Treatment of wastewater with high chroma and low dissolved oxygen.Such as textile printing and dyeing wastewater treatment .
4.Treatment of oxide-rich wastewater containing algae.
5.Treatment of low temperature and low turbidity sewage.
6.Replace secondary sedimentation tank, suitable for the situation that is easy to produce sludge swelling;It is suitable for the concentration of residual activated sludge and convenient for the treatment of filter press.
ABOUT US
Wastewater Pre-treatment Dissolved Air Flotation and Micro-Bubble Adsorption Treatment 5
OUR SERVICE
Wastewater Pre-treatment Dissolved Air Flotation and Micro-Bubble Adsorption Treatment 6
Wastewater Pre-treatment Dissolved Air Flotation and Micro-Bubble Adsorption Treatment 7
Product Performance:

1.The DAF machine relies on a large number of micro-bubbles to remove the flocculation of the adhesion reaction,so the flocculation requirements are not high ,which can reduce the flocculation time and save the flocculation agent.

2.High yield per unit area,small pool capacity and floor area,saving land and cost.

3.Convenient sludge discharge ,low water consumption;low moisture content of sludge.

4.Shallow tank body depth ,simple tank structure .The machine can be opened and stopped at any time according to the situation and the actual needs , without affecting the water quality ,easy operation and maintenance.
RECOMMEND PRODUCT
Wastewater Pre-treatment Dissolved Air Flotation and Micro-Bubble Adsorption Treatment 8
PACKAGING AND TRANSPORTATION
Wastewater Pre-treatment Dissolved Air Flotation and Micro-Bubble Adsorption Treatment 9
FAQ
Q: How to buy your incinerator?
A: You can provide us the waste kind and waste quantity(connect us for more details). we will recommand you the suitable model incinerator.

Q: How to pay?
A: TT and L/C are acceptable and TT will be more appreciated. 30% deposit before producing, 70% balance before loading by TT.

Q: What is the delivery time?
A: It depends on order quantities. Generally speaking, the delivery time will be within 3 to 4 weeks.

Q: How to install after the equipments arriving destination?
A: We will provide detailed illustrations to you. And we will send a technician to guide for installation and debugging. After debugging equipment, he will teach your workers how to use it and how to maintain it.
