Product Details:
Place of Origin: Shandong, China
Brand Name: BETTER
Certification: CE ISO9001
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: $8,800.00/pieces 2-2 pieces
Packaging Details: Seaworthy packing-- garbage incinerator,poultry incinerator,mini waste incinerator
Supply Ability: 20 Set/Sets per Month

Garment Shops MBR and Biological Treatment Integration Device with 1 of Core Components

Description
Condition: New Applicable Industries: Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Advertising C
Showroom Location: Italy, France, Germany, Viet Nam, India, Mexico, Russia, Spain, Thailand, Kenya, Argentina, Chile, Colombia, Romania, South Africa, Australia Video Outgoing-inspection: Provided
Machinery Test Report: Provided Marketing Type: Hot Product 2023
Warranty Of Core Components: 1 Year Core Components: Gearbox, Pressure Vessel, Pump, Motor, PLC, Air Blower
Material: Seaworthy Packing, Stainless Steel /carbon Steel Weight: 1000kg
Size: Different As Each Model Power: Different As Each Model
Warranty: 1 Year Productivity: 0.5-30t/h
Weight (KG): 1000 Kg Product Name: Water Treatment System
Application: Wastewater Treatment Plant Type: Pure Water Treatment System
Color: White/blue Black Technology: Membrane Separation + Biological Treatment
Capacity: 0.5-30t/h Shape: Rectangle
Advantage: 24 Hours Automatic Running Port: Port Of Qingdao

Garment Shops MBR and Biological Treatment Integration Device with 1 of Core Components 0
Garment Shops MBR and Biological Treatment Integration Device with 1 of Core Components 1
What is the MBR?
I. Product Overview
Membrane Bioreactor (MBR) is a kind of advanced technology developed since the end of 20th century which realized the efficient combination of membrane separation technology with biological technology. The membrane separation technology replaces the traditional active sludge method and the normal filter unit, its strong separation ability can make the SS turbidity near to be zero. Hydraulic retention time (HRT) sludge age (SRT) is completely separated, the outlet water is good and stable in quality, it can be reused without the third level treatment. Due to the high security and economic and effective water, it greatly expands the scope of application of waste water recycling.

Technological Process:
Sewage → Grille → Regulating pond → MBR Bioreactor → Discharge(reuse)
1. Temperature: 5℃~45℃, average membrane aperture 0.10 μm.
2. PH: 2~12, membrane thickness: 40μm.
3. Outlet water turbidity: <1 NTU , outlet water SS <1mg/L.
4. Membrane area: 8m2, advised gas-water ratio: 25:1~30:1.
5. Operating pressure: -0.01 ~ -0.03MPa.

Garment Shops MBR and Biological Treatment Integration Device with 1 of Core Components 2
Garment Shops MBR and Biological Treatment Integration Device with 1 of Core Components 3
Garment Shops MBR and Biological Treatment Integration Device with 1 of Core Components 4
Features:
1. Because of the high-efficiency solid-liquid separation, it can efficiently remove the SS, colloidal material and dead microbe in the sewage, no need sedimentation tank, or filter device, nor other solid-liquid separation device.
2. The MBR can make the biomass in biological treatment unit maintain high concentration, thus highly improve the volume loading. Meanwhile, the high efficient membrane separation can shorten the HRT. The device is with a compact structure and small space occupation.
3. MBR can filter out bacteria, part of the harmful material such as virus, it can obviously save dosing disinfection dosage,
greatly improve the quality of the output water and reduce the operating cost and widen the scope of application of water.
4. Due to the strong interception function of MBR, it can keep the microbe in the reactor to avoid the loss of all kinds of
microbe groups, which is good for the growth of the bacteria (such as the nitrifying bacteria), at the same time, it can lengthen the residence time of difficult degradable macromolecule organics to improve the decomposition so as to make the metabolic system process smoothly. The system has a strong impact resistance and wide suitability.
5. It can realize the completely separation of HRT and SRT. By the extended aeration, it can consume the organics, it can
theoretically achieve the effect of no excess sludge emissions, thus reduce the surplus sludge treatment cost significantly.
6. The unique mode of operation makes the membrane surface no blocking, and the cleaning interval time is long. The way to clean the membrane is easy, since the membrane module can be separately cleaned, thus, the maintenance is convenience and simple. The module design make the machine flexible, it is easy to expand the volume.
Garment Shops MBR and Biological Treatment Integration Device with 1 of Core Components 5
Category
Raw water quality(mg/l)
Treated water quality(mg/l)
BOD5(mg/l)
150-250
<10
COD(mg/l)
200-400
<50
SS(mg/l)
150-250
<10
Ammonia nitrogen(mg/l)
10-35
5(8)
Garment Shops MBR and Biological Treatment Integration Device with 1 of Core Components 6
Garment Shops MBR and Biological Treatment Integration Device with 1 of Core Components 7
Garment Shops MBR and Biological Treatment Integration Device with 1 of Core Components 8
Garment Shops MBR and Biological Treatment Integration Device with 1 of Core Components 9
Garment Shops MBR and Biological Treatment Integration Device with 1 of Core Components 10
Garment Shops MBR and Biological Treatment Integration Device with 1 of Core Components 11
Garment Shops MBR and Biological Treatment Integration Device with 1 of Core Components 12
Garment Shops MBR and Biological Treatment Integration Device with 1 of Core Components 13
Garment Shops MBR and Biological Treatment Integration Device with 1 of Core Components 14
Garment Shops MBR and Biological Treatment Integration Device with 1 of Core Components 15
Garment Shops MBR and Biological Treatment Integration Device with 1 of Core Components 16
Garment Shops MBR and Biological Treatment Integration Device with 1 of Core Components 17
Q: How to pay?
A: TT and L/C are acceptable and TT will be more appreciated. 30% deposit before producing, 70% balance before loading by TT.

Q: What is the delivery time?
A: It depends on order quantities. Generally speaking, the delivery time will be within 3 to 4 weeks.

Q: How to install after the equipments arriving destination?
A: We will provide detailed illustrations to you. And we will send a technician to guide for installation and debugging. After
debugging equipment, he will teach your workers how to use it and how to maintain it.

Q: How to visit your factory?
A: You could fly to Qingdao airport and we will pick up you to our company.
